New Holland WORKMASTER 25S Open-Air + 100LC LOADER + 160GMS MOWER

Double tap to zoom

Workmaster™ 25S Sub-Compact WORKMASTER 25S Open-Air + 100LC LOADER + 160GMS MOWER
EMISSIONS LEVEL
T4B FINAL
GROSS HORSEPOWER [HP (KW)]
24.7 (18.4)
-
Get a Quote
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
-
Request Brochure
Request Brochure
Fields with asterisks* are required.
-
Send to a Friend
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
-
Payment Calculator
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.
Share This Product:
Features
WORKMASTER™ 25S Sub-Compact
THE TRADITION OF VALUE CONTINUES
Whether you are a homeowner with acreage to maintain, an Ag-lifestyler with a food plot or a sundowner with livestock to tend to do yourself a favor and check out New Holland's WORKMASTER™ family of compact tractors. Known for delivering outstanding value these reliable, powerful and easy-to-operate WORKMASTER compacts will help you complete tasks efficiently while being easy on your wallet. The latest member of the WORKMASTER compact family, the WORKMASTER 25S sub-compact, is available in Open-air ROPS platform and cab variants and carries on the WORKMASTER tradition.
OPEN AIR PLATFORM
CLEAR-THRU™ - EASY ON AND OFF
The Clear-Thru operator's platform makes getting on and off quick and safe. Controls are placed out of the way so they don't impede platform entry/exit and because the platform is flat you won't be catching your foot on any transmission hump. Once in the WORKMASTER's seat, you will be surprised at just how much room there is - impressive for a sub-compact tractor.
CAB
SPACIOUS CAB KEEPS YOU COMFORTABLE ALL DAY
Big levels of comfort and visibility await you in the new WORKMASTER™ 25S cab. Its 4-post design features plenty of glass for exceptional visibility, and two doors mean entry/exit is easy.
Specifications
WM25S + 100LC LDR + 160GMS MMM | |
Engine | |
Emissions Level | T4B Final |
Gross horsepower hp (kW) | 24.7 (18.4) |
Rated speed rpm | 3000 |
No. of cylinders | 3 |
Aspiration | Natural |
Displacement cu.in. (L) | 77.3 (1.26) |
Alternator amps | 50 |
Fuel Tank gal. (L) | 6.6 (25) |
PTO | |
PTO horsepower hp (kW) | 17.2 (12.8) |
PTO speed rpm | 540 |
PTO type | Independent Electro-Hydraulic Engagement |
Mid-PTO | Standard |
Mid-PTO speed rpm | 2500 |
Transmission | |
Type/Control - Choice 1 | 2 Range Hydrostatic/Dual Pedal |
Type/Control - Choice 2 | N/A |
Maximum forward speed mph (kph) | 9.1 (14.7) |
Cruise control | Standard HST |
Gear/shuttle type | Synchro |
Rear diff-lock engagement | Mechanical |
Brake type | Wet, Multi-Disc |
Hydraulics & 3-Point | |
Implement hydraulic flow gpm (lpm) | 4.6 (17.4) |
Steering hydraulic flow gpm (lpm) | 2.1 (8) |
Total Flow gpm (lpm) | 6.7 (25.4) |
Remote Valves | 1 Opt. |
3-Point hitch | Chain Type Stabilizers /Fixed Link Ends |
3PT lift capacity @ ball ends lb. (kg) | 992 (450) |
3PT lift capacity @ 24 in. (610 mm) behind ball ends lb. (kg) | 728 (330) |
3-Point linkage category | I |
Front Axle Options | |
Two-Wheel Drive | N/A |
Four-Wheel Drive | Standard |
Dimensions/Weight | |
Wheelbase in. (mm) | 56.1 (1425) |
Length in. (mm) | 97.4 (2473) |
Width Width in. (mm) | 46.7 (1187) |
Height (top of ROPS or Cab) in. (mm) | 87.4 (2220) |
Weight in. (mm) | 1444 (655) |
100LC Loader | |
Lift Capacity (max height) lb. (kg) | 1005 (456) |
Lift Height in. (mm) | 72 (1829) |
Bucket | 50 inch/Pin on |
Weight lb. (kg) | 363 (165) |
160GMS Mower | |
Cutting Width | - |
# of Blades in. (mm) | - |
Weight | - |
905GBL Backhoe | |
Digging Depth in. (mm) | 79.4 (2017) |
Bucket | 9" |
Weight lb. (kg) | 707 (321) |
