New Holland Boomer 35
Double tap to zoom
Boomer Series 30-45 HP (PRIOR MODELS) Boomer 35
-
Get a Quote
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
-
Request Brochure
Request Brochure
Fields with asterisks* are required.
-
Send to a Friend
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
-
Payment Calculator
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.
Share This Product:
Features
Whether you use your tractor to maintain a few acres or you depend on it to make a living, Boomer™ compact tractors will deliver. In all, there are four models ranging from 28–47 hp to choose from. As a rule of thumb, the more work you do in a typical week, the greater the horsepower you’ll want.
Specifications
|
Model |
Boomer 35 |
| Brakes | |
|
Service brakes |
Dual-pedal mechanically actuated wet disc |
|
Parking brake |
Engage hand-lever, foot-assist service brake |
| Dimensions / Weight | |
|
Approx shipping length, in (mm) (w/ R4 tires) |
119 (3017) |
|
Approx shipping width, in (mm) (w/ R4 tires) |
64 (1618) |
|
Approx shipping hieght, in (mm) (w/ R4 tires) |
91 (2291) |
|
Approx shipping weight, lbs (kg) (w/ R4 tires) |
2913 (1321) |
| Electrical | |
|
Battery capacity (Amp hours / cold cranking amps) |
80/660 |
|
Lighting |
2 - hi/lo beam halogen headlights, 2 - halogen front-corner work lights, 2 - tail / brake lights, 2 - hazard / turn signals |
|
Instrumentation |
Analog tachometer, fuel gauge, coolant temperature, hour meter. |
|
Alternator |
12 volt, 50 amp |
| Engine | |
|
Type |
4-cylinder, diesel |
|
Number of cylinders / Aspiration |
4 / Natural |
|
Displacement, cu. in. (L) |
108 (1.76) |
|
Gross engine power, hp (kW) |
38 (28) |
|
PTO horsepower, hp (kW) - Gear |
32.2 (24.0) |
|
PTO horsepower, hp (kW) - HST |
30.3 (22.6) |
|
Rated speed (rpm) |
2700 |
|
Fuel type |
Standard diesel fuels or B2 Biodiesel (meeting ASTM 6751 standards) |
|
Air filter |
Dual element, dry type with cleanable outer element and replaceable inner safety element |
|
Lubrication |
Full flow, pressure feed lubrication with spin-on filter cartridge |
|
Emissionization standard |
Tier III |
|
Fuel tank capacity, gal (L) |
8.7 (33) |
|
Exhaust Type |
Under hood |
|
Foot Throttle |
Standard |
|
Cold Start Aid |
Glow Plug |
| Front Axle | |
|
FWD Axle |
Standard |
|
Front differential lock |
Limited slip |
|
FWD clutch engagement |
Mechanical lever |
| Hydraulics | |
|
System type |
Open center, fixed displacement gear pump |
|
Implement pump capacity, gpm (lpm) |
8.2 (31.2) |
|
Steering & services system, gpm (lpm) |
Hydrostatic power steering w/dedicated gear pump, 4.1 (15.6) |
|
Total maximum tractor flow, gpm (lpm) |
12.3 (46.8) |
|
Remote valves |
Optional; max of 2 open center, rear mounted, 3 position, self centering. |
|
Loader control valve |
Optional |
| Operator Area / General | |
|
Seat |
Fore / Aft / Weight adjustable with spring suspension |
|
Operator Floor |
Sound dampening, anti-slip rubber mat |
|
Steering column |
Tilting |
|
Cup holder / Tray |
Standard |
|
Hood design |
One piece, flip-up hood on gas strut |
|
ROPS |
Foldable |
| PTO | |
|
Rear PTO |
Electro-hydraulic engaged, Independent 540-RPM, w/ flip-up PTO shield |
|
Mid PTO |
Optional - Independent 2000RPM |
| Rear 3-Point Hitch | |
|
Category |
Category I |
|
Position control |
One lever - Mechanical |
|
Drop rate control |
Standard |
|
Draft control |
Optional - Top Link sensing |
|
Drawbar |
2-position swinging / extendable |
|
OECD lift capacity @ ball ends, lbs (kg) |
1,807 (820) |
| Rear Axle | |
|
Rear differential lock |
Mechanical foot pedal engagement |
| Transmission | |
|
Traction clutch - Gear transmission |
Dry, 9.4-inch (240 mm) diameter organic plate |
|
Type - Gear |
12Fx12R with 4 syncronized gears, 3 constant mesh ranges and synchronized dash-mounted shuttle |
|
Type - HST |
3 Range, dual-pedal (Fwd/Rev) hydrostatic transmission |
|
Cruise Control |
Standard on HST |
