Browse Equipment2023 New Holland C232 Skid Steer-Track For Sale
BACK
Quick View | 13 Photos- Price
-
CALL FOR PRICE & AVAILABILITY
- Description
- New, For Sale, 74 Horsepower
- Stock #
- Serial
Berchtold Equipment Co
Bakersfield, CASe Habla Español
Details
- Make: New Holland
- Model: C232
- Year: 2023
- HP: 74
- Overall Condition: New
Notes
- Manufacturer/model FPT / F5H FL463A*F001
Bore/stroke, in (mm) (3.9 x 4.3) 99 x 110
Displacement, in3 (L) 207 (3.4)
Fuel injection HPCR Direct
Air intake Turbocharged Aftercooled with external EGR
Horsepower per SAE J1349 Gross hp (kW) 74 (55) @ 2500 rpm
Horsepower per SAE J1349 Net hp (kW) 68 (51) @ 2500 rpm
Peak torque, lb-ft (Nm) 232 (314) @ 1400 rpm - Travel speed, low range, mph (km/h) 5.1 (8.2)
Travel speed, high range (optional), mph (km/h) 7.6 (12.2) - Bucket hinge pin, in (mm) 131.1 (3330)
Top of ROPS, in (mm) 80.4 (2043)
Bottom of level bucket, fully raised, in (mm) 124.2 (3155)
Overall length without attachment with coupler, in (mm) 117.8 (2993)
Dump angle, degrees 54.7
Dump reach (max height), in (mm) 34.4 (875)
Rollback, bucket on ground, degrees 32.8
Rollback, bucket at full height, degrees 84.8
Track on ground, in (mm) 64.5 (1639)
Ground clearance (bottom of belly pan), in (mm) 9.5 (243)
Angle of departure, degrees 32
Clearance circle without bucket, in (mm) 56.2 (1428)
Clearance circle rear, in (mm) 70.4 (1789)
Overall width, in (mm) 76 (1930)
Ground pressure, PSI (with spec belt) 4.2 - Pump Flow, gpm (Lpm) 24.2 (91.5)
Optional High Flow, gpm (Lpm) 37.6 (142.5)
Enhanced High Flow, gpm (Lpm) 3046 (210)
Relief Pressure, psi (bar) - - Rater Operating Load @50% tip, lbs (kg) 3200 (1451)
Rater Operating Load @ 35% tip, lbs (kg) 2240 (1018)
Tipping Load, lbs (kg) 6400 (2902)
Breakout Force, lift cylinder, lbs (kN) 4840 (21.5)
Breakout force bucket cylinder, lbs (kN) 7360 (32.7)
Operating Weight, lbs (kg) 9630 (4370)
