Bobcat MT85

Features
Performance Features
Unmatched power to help you push through your toughest jobs.
Attachment Features
The industry leader in attachments and attachment-ready features.
Comfort Features
More standard comfort features make hard work easier.
Serviceability Features
Reduce your operating costs through preventative maintenance that gets completed quickly.
Specifications
Model | Bobcat MT85 |
ENGINE | |
Emissions Tier (EPA) | Tier 4 |
Engine Cooling | Liquid |
Engine Fuel | Diesel |
Displacement | 55 in³ |
Number of Cylinders | 3 |
PERFORMANCE | |
Rated Operating Capacity (SAE) | 850 lb |
Tipping Load | 0 lb |
Operating Weight | 3110 lb |
Ground Pressure (Rubber) | 4.9 psi |
Travel Speed | 4 mph |
Travel Speed - Reverse | 2.4 mph |
CAPACITIES | |
Fuel Tank | 7 gal |
HYDRAULIC SYSTEM | |
Pump Capacity | 12 gal/min |
System Relief @ Quick Couplers | 2,900 psi |
Auxiliary Std Flow | n/a |
DIMENSION | |
Length | 106.2 in |
Width | 35.6 in |
Height | 54.6 in |
Height to Bucket Hinge Pin | 80.9 in |
Length of track on ground | 40.6 in |
Reach @ Maximum Height | 18.6 in |
FEATURES | |
Lift-Arm Support | Standard |
Auxiliary Hydraulics | Standard |
Spark Arrestor Muffler | Standard |
Bob-Tach Attachment System | Optional |
Reverse Travel Stop Panel | N/A |
Wide Track | Optional |
Neutral Start Interlocks | Standard |
Lift Arm Lockout With Manual Bypass | Standard |
Tilt Lockout | Standard |
Built-In Tie Down & Crane/Lift | Standard |
Locations | |
Ride-on Platform | Standard |
