Unmatched power to help you push through your toughest jobs.
The industry leader in attachments and attachment-ready features.
More standard comfort features make hard work easier.
Reduce your operating costs through preventative maintenance that gets completed quickly.
|Emissions Tier (EPA)||Tier 4|
|Number of Cylinders||3|
|Rated Operating Capacity (SAE)||850 lb|
|Tipping Load||0 lb|
|Operating Weight||3110 lb|
|Ground Pressure (Rubber)||4.9 psi|
|Travel Speed||4 mph|
|Travel Speed - Reverse||2.4 mph|
|Fuel Tank||7 gal|
|Pump Capacity||12 gal/min|
|System Relief @ Quick Couplers||2,900 psi|
|Auxiliary Std Flow||n/a|
|Height to Bucket Hinge Pin||80.9 in|
|Length of track on ground||40.6 in|
|Reach @ Maximum Height||18.6 in|
|Spark Arrestor Muffler||Standard|
|Bob-Tach Attachment System||Optional|
|Reverse Travel Stop Panel||N/A|
|Neutral Start Interlocks||Standard|
|Lift Arm Lockout With Manual Bypass||Standard|
|Built-In Tie Down & Crane/Lift||Standard|
