Browse EquipmentNew Holland Haybine® 14HS
Features
REDESIGNED FOR FASTER SPEED
Durabine PLUS Series disc headers take advantage of faster speeds on Speedrower® PLUS windrowers without compromising cutting and conditioning quality.
CLEAN & CLOSE CUTTING
The MoxMax™ II PLUS true modular cutterbar found on Durabine PLUS heads provides an even cleaner cut with faster tip speed and a lower-profile compared to previous models.
LEGENDARY PERFORMANCE
HS Series Haybine sickle headers continue the legacy of impeccable cutting performance, fast drying, and time-tested reliability.
UNIFORM, FAST-DRYING SWATHS
Choose the best conditioning system for your crops – rubber chevron rolls, steel chevron rolls, or high-contact chevron rolls.
Specifications
| Dimensions & Weights | |
| MODEL | Haybine® 14HS |
| Cutting width ft. in. (m) | 14' 3" (4.34) |
| Overall width ft. in. (m) | 16' 3" (4.95) |
| Weighting with conditioning system lbs. (kg) | 3900 (1770) |
| Weight less conditioning system lbs. (kg) | – |
| Durabine PLUS MowMax™ II PLUS Cutterbar | |
| Cutting width ft. in. (m) | – |
| Cutting height range in. (mm) | – |
| Cutting angle | – |
| Number of discs | – |
| Maximum disc speed rpm | – |
| Number of reversible | swing-away knives |
| Knife tip speed mph (kph) | – |
| Flotation | – |
| ShockPRO™ Disc Drive Protection System | – |
| 3-Year MowMax Factory Cutterbar Warranty | – |
| Haybine Cutterbar | |
| Cutting width ft. in. (m) | 14' 3" (4.34) |
| Cutting height range in. (mm) | 1.2-6.2 (30.5-157.5) |
| Cutting angle | -6 to -12 degrees |
| Type | Timed |
| Knives | Over serrated |
| Guards | 2-tine |
| Skid shoes | 4 |
| Drive type | Open |
| Speed spm | 1810 |
| Stroke in. (mm) | 3 (76) |
| Haybine Reel | |
| Type | 5 bat |
| Adjustments | Fore/aft and vertical |
| Mechanical drive rpm | 58 - 83 |
| Hydraulic drive (optional) rpm | 0 - 76 |
| Speed adjustment (mechanical) | Variable sheave |
| Diameter in. (mm) | 42 (1067) |
| Drive type | Belt and chain |
| Tine bars | Segmented |
| Bushings / bearings* in. (mm) | 1.25 (31.75) |
| Auger | |
| Auger diameter in. (mm) | 20 (508) |
| Auger type | Floating |
| Conditioning Systems | |
| Roll types | Chevron-pattern rubber or steel |
| Roll length in. (mm) | 102 (2591) |
| Roll diameter in. (mm) | 10 .16 (258) |
| Roll speed rpm | 717 |
| Roll pressure | Hand crank |
| Roll gap | Adjustable stop-bolt |
| Roll drive | Spur gearbox and PTOs |
| Windrow/swath width in. (mm) | 38 to 96 (965 to 2438) |
|   |
