Unmatched power to help you push through your toughest jobs.
Uptime Protection Features
Intelligently designed components keep you on the job working.
More standard comfort features make hard work easier.
Easy maintenance routines give you dependable performance and peace of mind.
|Emissions Tier (EPA)||Tier 4|
|Maximum Governed RPM||2,100 rpm|
|Operating Weight||18,960 lb|
|Weight Class||8.6 t|
|Travel Speed - High||2.9 mph|
|Travel Speed - Low||1.7 mph|
|Arm Digging Force||8,069 lbf|
|Bucket Digging Force||14,509 lbf|
|Rated Lift Capacity||9327 lb|
|Lift Radius||118 in|
|Boom Swing - Left||70°|
|Boom Swing - Right||55°|
|Maximum Dig Depth||15.5 ft|
|Max Dump Height||16.5 ft|
|Maximum Reach at Ground Level||23.9 ft|
|Fuel Tank||29.1 gal|
|Auxiliary Std Flow||25.1 gal/min|
|Auxiliary Pressure||3,045 psi|
|Overall Length in Travel Position||158.4 in|
|Height with Operator Cab||104 in|
|Heater Air Conditioning||Standard|
|Tail Swing Type||Minimal|
|Secondary Auxiliary Hydraulics||Optional|
|Quick Tach System||Optional|
|Selectable Auxiliary Hydraulic Flow||Standard|
