Unmatched power to help you push through your toughest jobs.
Uptime Protection Features
Intelligently designed components keep you on the job working.
More standard comfort features make hard work easier.
Easy maintenance routines give you dependable performance and peace of mind.
The industry leader in attachments and attachment-ready features.
|Emissions Tier (EPA)||Tier 4|
|Maximum Governed RPM||2,100 rpm|
|Operating Weight||13,779 lb|
|Weight Class||6.3 t|
|Travel Speed - High||2.9 mph|
|Travel Speed - Low||1.6 mph|
|Arm Digging Force||5,767 lbf|
|Bucket Digging Force||9,731 lbf|
|Rated Lift Capacity||5902 lb|
|Lift Radius||118 in|
|Boom Swing - Left||70°|
|Boom Swing - Right||50°|
|Maximum Dig Depth||13.5 ft|
|Max Dump Height||14 ft|
|Maximum Reach at Ground Level||20.4 ft|
|Fuel Tank||20.6 gal|
|Auxiliary Std Flow||22.5 gal/min|
|Auxiliary Pressure||3,046 psi|
|Overall Length in Travel Position||147.6 in|
|Height with Operator Cab||100.4 in|
|Heater Air Conditioning||Standard|
|Tail Swing Type||Conventional|
|Secondary Auxiliary Hydraulics||Optional|
|Quick Tach System||Standard|
|Selectable Auxiliary Hydraulic Flow||Standard|
