Unmatched power to help you push through your toughest jobs.
Uptime Protection Features
Intelligently designed components keep you on the job working.
More standard comfort features make hard work easier.
Easy maintenance routines give you dependable performance and peace of mind.
The industry leader in attachments and attachment-ready features.
|Emissions Tier (EPA)||Tier 4|
|Maximum Governed RPM||2,500 rpm|
|Operating Weight||4,306 lb|
|Weight Class||2 t|
|Travel Speed - High||2.5 mph|
|Travel Speed - Low||1.5 mph|
|Arm Digging Force||2,086 lbf|
|Bucket Digging Force||4,684 lbf|
|Rated Lift Capacity||1023 lb|
|Lift Radius||118 in|
|Boom Swing - Left||80°|
|Boom Swing - Right||60°|
|Maximum Dig Depth||8.5 ft|
|Max Dump Height||8.8 ft|
|Maximum Reach at Ground Level||14 ft|
|Fuel Tank||5 gal|
|Auxiliary Std Flow||7.9 gal/min|
|Auxiliary Pressure||2,610 psi|
|Overall Length in Travel Position||145.2 in|
|Height with Operator Cab||90.4 in|
|Heater Air Conditioning||N/A|
|Tail Swing Type||Zero|
|Secondary Auxiliary Hydraulics||N/A|
|Quick Tach System||N/A|
|Selectable Auxiliary Hydraulic Flow||Optional|
