Heavy Duty 1/2” End Plate features large 2 3/16” knife drum bearings with “seal guards”. Slotted end plates provide ease of knife drum and depth roller
removable. Smooth, Strong Case with wear liner provides an even and unobstructed material flow. Large 7” discharge area over depth roller eliminates material interference. Extra Strong 1/2” A frame and tubular braces is reinforced by additional wrap around case plates. Heavy-duty gear box with hardened forged steel
gears and tapered roller bearings. Heavy Duty Self-Adjusting Belt Drive has easy access with hinged safety shield. Heavy duty 5vx belt provides long trouble-free belt life.
- Quickchange knives and "D" Rings
- Available in widths of 9',10',11',12',13',14', and 15'
- Adjustable to various cutting heights
- Moving parts are shielded
- Heavy Duty 1/2" end plate
- Large 7" discharge area over depth roller eliminates material interference
- Heavy Duty self-adjusting belt drive
