New Holland T8.360

T8 Series - Tier 4A T8.360

Double tap to zoom



Features

MORE POWER AND PRODUCTIVITY

Every T8 model boasts the new performance of New Holland's EcoBlue Tier 4 engine solutions.



ABSOLUTE DRIVING PLEASURE

New Holland SideWinder II armrest makes the T8 Series intuitive to operate for reduced fatigue.



MAXIMUM VERSATILITY

T8 tractors defy the status quo with a revolutionary long-wheelbase design.



LOWER OPERATING COST

Operating costs for the new T8 tractors with EcoBlue have been reduced by 10% when compared to existing Tier 3 models-even when the cost of AdBlue Diesel Exhaust Fluid (DEF) is taken into account.



Specifications

Model T8.360
Engine

Type

New Holland FPT Cursor 9L

Aspiration

Waste-gate Turbocharger, air-to-air after cooled

Displacement

543 (9)

Rated Engine Speed

2000

Rated power hp (kw)

307 (229)

Max Power - EPM hp [CV] (kw)

358 (263)

Peak Torque lb-ft (Nm)

1,129 (1,531)

PTO hp (kW) **

265 (198)

PTO torque rise **

42%

PTO Power Growth, hp (kW) **

31 (23)
Electrical

Alternator

200 amp, 12-volt
Transmission

Standard.

18F/4R Power Shift

Optional

**19F/4R Power Shift.

Optional.

23F/6R Power Shift

Optional..

19F/4R 31 mph (50 kph)
Axles

Standard Front axle

FWD

Optional....

Terraglide™ FWD

Tread spacing adjustment, in. (mm)

60 to 88 (1524 to 2235)

Rear axle length, in. (mm)

120 (3050)

Standard rear axle diameter, in. (mm)

4.5 (115)

Optional rear axle diameter, in. (mm)

NA
Hydraulics

Type.

CCLS

Remote Valves Standard

4

Optional Remote Valves

up to 6

Standard flow, gpm (l/min)

42.5 (161)

Optional MegaFlow™, gpm (l/min)

72.3 (274)

Max Flow - One Remote U.S. Gal (L)

35 (133)
3-Point Hitch

Type..

Cat IIIN / III

Standard lift capacity, lbs. (kg)

16,375 (7421)

Optional lift capacity, lbs. (kg)

17,931 (8132)
PTO

Standard

1 3⁄4",1000 rpm

Optional...

1 3⁄4", 1 3⁄8" 1000/540 rpm
Brakes

Standard on front and rear axle

Integral hydraulic wet disk
Capacities

Fuel tank, U.S. gal (L)

168 (637)

DEF Tank, U.S. Gal (L)

24 (91)
Dimensions**

Width, in. (mm)

120 (3050)
Maximum Operating Weight

T8 Series, lbs. (kg)

34,425 (15,650)
Shipping Weight

Standard FWD, lbs. (kg)**

24,480 (11,127)

TerraGlide FWD, lbs. (kg)**

25,280 (11,490)
Dimensions**

Wheelbase, in. (mm) FWD and Terraglide™ FWD

135.8 (3450)
