New Holland Boomer 25

Boomer Series 23-27 HP (PRIOR MODELS) Boomer 25

Double tap to zoom



Features

For dependability you can count on, Boomer™ 20/25 compact tractors featuring powerful Mitsubishi diesel engines deliver 23 or 27 hp. What's more, the majority of the gross engine horsepower gets turned into usable power at the PTO to run a variety of implements thanks to an ultra-efficient driveline.

Specifications

Model

Boomer25
Engine

Type

Mitsubishi S3L2

Number of cylinders / Aspiration

3-cylinder, diesel

Displacement, cu. in. (L)

80.4 (1.3)

Gross engine power, hp (kW)

27(19.9)

PTO horsepower, hp (kW) - Gear

N/A

PTO horsepower, hp (kW) - HST

19.9(14.7)

Rated speed (rpm)

2700

Fuel type

Standard diesel fuels or B2 Biodiesel (meeting ASTM 6751 standards)

Air filter

Single element, dry type

Lubrication

Full flow, pressure feed lubrication with spin-on filter cartridge

Emissionization standard

Tier 4a

Fuel tank capacity, gal (L)

6.6 (25)

Exhaust Type

Under Hood

Foot Throttle

Standard

Cold Start Aid

Glow Plug
Transmission

Traction clutch - Gear transmission

N/A

Type - Gear

N/A

Type - HST

2 Range, treddle peddle, hydrostatic transmission

Cruise Control

Standard
Hydraulics

System type

Open center, fixed displacement gear pump

Implement pump capacity, gpm (lpm)

6.0 (22.9)

Steering & services system, gpm (lpm)

Hydrostatic power steering w/dedicated gear pump - 2.5 (9.5)

Total maximum tractor flow, gpm (lpm)

8.5 (32.4)

Remote valves

Optional; max of 1 open center, rear mounted.

Loader control valve


Rear 3-Point Hitch

Category

Category I

Position control

One lever - Mechanical

Drop rate control



Draft control

N/A

Drawbar

1-position fixed

OECD lift capacity @ ball ends, lbs (kg)

1,433 (650)
PTO

Rear PTO

Electro-hydraulic engaged, Independent 540-RPM, w/ PTO shield

Mid PTO

Standard - Independent 2000RPM
Electrical

Alternator

12 volt, 50 amp

Battery capacity (Amp hours / cold cranking amps)

45/560

Lighting

2 - hi/lo beam halogen headlights, 2 - tail / brake lights, 2 - hazard / turn signals

Instrumentation

Digital tachometer & hour meter; Analog fuel guage & coolant temperature
Brakes

Service brakes

Single-pedal, left side mounted, mechanically actuated wet disc

Parking brake

Engage hand-switch, foot-assist service brake
Front Axle

FWD Axle



Front differential lock

Limited slip

FWD clutch engagement

Mechanical lever
Rear Axle

Rear differential lock

Mechanical foot pedal engagement
Operator Area / General

Seat

Fore / Aft adjustable with spring suspension

Operator Floor

Sound dampening, anti-slip rubber mat

Steering column

Fixed

Cup holder / Tray



Hood design

One piece, flip-up hood on gas strut

ROPS

Foldable
Dimensions / Weight

Approx Shipping Length, in (mm) (w/ R3 tires)

103.6 (263.2)

Approx Shipping Width, in (mm) (w/ R3 tires)

43.8 (1115)

Approx Shipping Height, in (mm) (w/ R3 tires)

85.5 (217.3)

Approx Shipping Weight, lbs (kg) (w/ R3 tires)

1,702 (772)
