New Holland 758GC

Heavy Duty Rotary Cutters 758GC

Double tap to zoom



Features

TAKE THE BITE OUT OF BIG JOBS
750 and 760 Series heavy-duty rotary cutters are rugged, hard working and designed to cover more ground quickly as you shred thick weeds, stocks and brush. Pick from four models and three cutting widths, all built tough for outstanding cutting capacity and years of worry-free performance.

TRACTOR COMPATIBILITY
Designed for use with utility, mid-range and high-horsepower tractors ranging from 40-150 hp and quipped with a Category II hitch.

BETTER BLADES
Choose from three cutting widths: 72, 84 or 96 inches, featuring heavy-duty ½ x 4-inch high-vacuum blades for a smooth, clean cut.

DURABLE GEAR BOX
Heavy-duty gearbox features a 1/2 inch gearbox plate for added reinforcement, and a five-year gearbox warranty limited to defects in workmanship and materials provides peace of mind.

HEFTY A-FRAME AND STUMP/DEBRIS JUMPER
Power through and around obstacles without harming your cutter, plus standard-equipment chain guards evenly deflect clippings.

STAY CLEAR OF DEBRIS
Bolt-on, counter-sunk skid plates are designed so they won't catch debris, and chain guards are standard equipment to deflect clippings.

HEAVY-DUTY SLIP-CLUTCH AND TOP LINK
Four-plate slip clutch and flexible top link provide extra protection.

Specifications

MODEL 758GC
Tractor hp (max.) 95 hp
Cutting Width 84"
Overall Width 90"
Overall Length 122"
Hitch 3-point
Driveline Category Category I
Gearbox Rating 95 hp
Gearbox Warranty 5 years
Slip Protection Slip Clutch
Deck Gauge 7 Gauge
Side Panel Depth 8" x 1/4"
Blade Carrier Pan
Output Shaft Diameter 2"
Blade Size 1/2" x 4" Updraft
Blade Tip Speed (540) 17,495 fpm
Cutting Height (min.) 2 inch
Tail Wheel Single Spindle
Tire & Wheel Laminated
Safety Deflectors Front/Rear Chains
Weight 1504 lbs.
